GSM Module WIFI Module 3G Module 4G Moudle 5G Module Signal Jammer

ブランド名: wolvesteam
モデル番号: JM311102-12M
MOQ: 1
価格: negotiated price
納期: 20日
支払い条件: LC、T/T
詳細情報
起源の場所:
中国
証明:
CE
出力電力:
30W/各バンド
妨害範囲:
距離 10-150M [信号強度はその場所で -80db 未満である必要があります]
カバーインターフェース規格:
AMPS、N-AMPS、NMT、TACS、GSM、CDMA、TDMA、IDEN、UMTS
自動切換電源:
50/60 Hz AC 100~240VからDC 12V
動作温度:
-10°C ~ +60°C
湿度:
95% 凝縮しない
アンテナ:
パッチアンテナ - 各バンドで5 dBiのゲイン
動作温度::
-10 ~ +60°C
パッケージの詳細:
箱 385 (L) × 340 (W) × 280 (H) mm
供給の能力:
100個/月
ハイライト:

GSM signal jammer module

,

3G 4G signal jammer

,

5G WiFi signal blocker

製品説明
GSM Module WIFI Module 3G Module 4G Module 5G Module Signal Jammer
Product Overview

Meeting Room Desktop Cell Phone Signal Jammer - This high-power indoor cell phone signal jammer effectively blocks GSM, CDMA, 3G, 4G, 5G, and WiFi 2.4G signals within an 80-meter range. Designed for professional environments requiring signal control, it features advanced cooling systems and continuous operation capabilities.

Key Specifications
Attribute Value
Output Power 30W / each band
Jamming Range 10-150 meters (signal intensity must < -80dB in location)
Covered Standards AMPS, N-AMPS, NMT, TACS, GSM, CDMA, TDMA, IDEN, UMTS 4G 5G
Power Supply Automatic switching 50/60 Hz AC 100-240V to DC 12V
Operating Temperature -10°C to +60°C
Humidity 95% non-condensing
Antenna Patch Antenna - Gain 5 dBi of each band
Technical Features
  • Blocks CDMA, GSM, DCS, PCS, 3G, 4G, and 5G signals simultaneously
  • High-power 50W design with extended jamming range
  • Waterproof construction for durability
  • Advanced cooling system for 24/7 continuous operation
  • RF frequencies only block downlink band, never uplink
  • Easy and fast installation
Frequency Specifications
  • 4G LTE1: 725-770MHz
  • 4G LTE2: 790-826MHz
  • CDMA 800: 850-894MHz
  • GSM 900: 925-960MHz
  • DCS1800: 1805-1880MHz
  • PCS 1900: 1905-1990MHz
  • 3G: 2110-2170MHz
  • 4G WIMAX1: 2300-2400MHz
  • 4G WIMAX2: 2570-2690MHz
  • 5G1: 3400-3600MHz
  • 5G2: 3600-3800MHz
  • WIFI 2.4G: 2400-2500MHz
Additional Specifications
Output Power 30W / each band
Jammer Modules 10
Device Dimensions 38.5cm (L) × 43cm (W) × 26.5cm (H)
Weight 1kg
Storage Temperature -30°C to +70°C
Applications
  • Meeting Rooms
  • Oil and Gas Storage Facilities
  • Hospitals
  • Theatres
  • Recording Studios
  • Banks
  • Contract Tendering Rooms
  • Churches
  • Conference Rooms
  • Classrooms
  • Testing Facilities
  • Security Services
  • Military Units
  • Secret Services
  • News Conference Rooms
  • Libraries
  • Museums
  • Prisons
  • Courts
  • Border Patrol and Drug Enforcement
  • Customs
  • Residential Areas
  • Small Prison Areas
Included Accessories
  • Power Adaptor
  • Remote Control
  • User Manual

The advanced cooling system design ensures reliable 24/7 continuous operation, making this high-power adjustable multi-purpose jammer ideal for demanding professional applications.
